For measuring aerosols (particles in the gas-phase): 気相中に浮遊する粒子の計測

• Aerosol particle generators: from Nanometer to Micrometer: For example combustion- or spray-based generators 燃焼型や噴霧型)
• Particle Counter: From nanometer to micrometer in the gas phase (mainly optical-based sensor) (For example: Condensation Particle Counters 凝縮粒子計数機)
• Aerosol Sizing: For size distribution of few nanometer to micro-meter particles in the gas phase. For example: ELPI/ 電子式低圧インパクター, SMPS/走査型移動度粒径測定器 (including DMA 微分型静電分級器）
• Fields inside TUAT (Fuchu campus) and 30-meter tower at FM多摩丘陵 (Hachioji)

  •





For measuring particles in the liquid-phase. 液相中に浮遊する微粒子の計測

• Dynamic Light Scattering (DLS) Malvern Instruments: Zetasizer Nano (Also can measure: zeta potential)
• Nanopore Platform, Scanning Ion Occlusion Sensing Method: Measurement of size distribution, concentration, surface charge | izon.com | meiwafosis.com/


For measuring gas (CO2, water)

• CO2 meter. RTR-576 is a three-channel data logger designed to measure and record CO2 concentration, temperature and humidity. Cloud｜Wireless｜Automated Data Collection. https://tandd.com/product/rtr576/ CO2: 0 to 9999ppm, Temperature: 0 to 55°C, Humidity: 10 to 95%RH

Programmable 3D Plotter CNC (Computer Numerical Control)

• Genmitsu PROVerXL 4030 . CNC router kit with pre-assembled XYZ axes and wiring for faster setup. Resolution = 0.1 ㎜. Paths of this tool can be programmed with G-code, which we can write manually or generate with a CAD/CAM software.  G-code is also used in 3D printers. >> Amazon. A rigid C-beam frame, NEMA 23 stepper motors, a high‑power spindle, and a Dewalt DWP611 holder. Lead-screw drives, dual Y-axis screws, and an optical Z drive. Suitable for milling, drilling, and engraving materials. Optional upgrades: 600×600 mm kit, 4th-axis rotary, and up to 15 W laser module. CNC 4030 GRBL parameters: bit.ly/3GIbkNl >> https://jp.sainsmart.com/products/genmitsu-cnc-proverxl-4030 CNCルーターキット。XYZ軸と配線は事前組立済み。再設計された制御ボックスと駆動系、頑強なC梁フレーム、高精度NEMA 23ステッピングモーター、ハイパワースピンドル、Dewalt DWP611用ホルダーを搭載。XYZリミットスイッチ、速度制御、Zプローブ等。リードスクリュー駆動、Y軸デュアルスクリュー、光学式Z駆動によりVスロット方式。切削・穴あけ・彫刻に最適。オプションで600×600mmキット、4軸ロータリー

Element analysis, 組成分析装置

• Inductively Coupled Plasma Mass Spectrometer ICP-MS (need revision)
• Micro CHN (Carbon, Hydrogen, Nitrogen) elemental analyzer (need revision)

• 成分元素や構成比率 Energy-Dispersive X-ray Fluorescence Spectrometer : Emission of characteristic “secondary” (or fluorescent) X-rays from a material that has been excited by bombarding with high-energy X-rays or gamma rays. From Na to U.  。エネルギー分散形蛍光X線分析装置は”固体・粉末・液体・薄膜など様々な試料が分析可能、標準試料無しに定量分析が可能” JEOL JSX-3100RII, 蛍光X線分析装置, 液体窒素フリー, Si(Li) 半導体検出器









Wavelength or Color Analysis

• MSV-370 Microscope attached UV-Visible-Near-IR spectrophotometer 微量高感度分光分析システム（顕微鏡と高性能分光光度計：顕微紫外可視近赤外分光光度計。紫外域から近赤外域にわたる広範囲な波長領域で微小試料や微小部位の透過・反射測定が行えます）Microspectroscopy system providing transmittance or reflectance measurements of microscopic sample sites. Measure color, film thickness, and other spectral properties of a microscopic area for either large or small samples. 250-2000 nm. Minimum spot* 30 micrometer. jasco.co.jp//microUV.html

• Color Analyzer (TES-3250) 色差を測定し、様々な単位系モードでの表示できる。L*, a*, b*色空間を用いたカラーセンサ ■99セットのデータ記録と読み出し可能。USBケーブル,ソフトウェアが付属 ■発光しない物、繊維、紙、革、塗装物などの非発光色の測定が可能 Capable of measuring non-luminous colors such as non-luminous objects, textiles, paper, leather, and painted objects　 色差の許容差の指定による色判定が可能 （PASS, WARN, FAIL）ゴム、塗料、模様、衣類、食物分野などで色の品質管理にも最適　Ideal for quality control of colors in rubber, paint, patterns, clothing, food, etc.









Crystallinity 結晶構造

• X-ray diffractometer (XRD) with heating system: RIKAGU

Softwares:

• COMSOL-Multiphysics. 数値シミュレーション, FEM based multi-physics. From fluid flow/heat transfer to structural mechanics and electromagnetic analyses @youtube. ： 伝熱、構造、流体、電気化学、電磁気、光、音響など
• IBM SPSS Statistics (「世界標準」統計ソフト) ANOVA etc.
• MatLab (MathWorks) 数値線形代数、関数とデータの可視化、アルゴリズム開発、グラフィカルインターフェイスや、他言語(C言語/C++/Java/Python)とのインターフェイスの機能を有している。MATLAB & Simulink (mathworks.com) From January 4, 2024: MathWorks社のMATLAB Campus‑Wide License（包括ライセンス）の運用を開始。MATLABおよびMathWorksが提供するほぼ全ての製品を、在籍する学生が台数無制限でいつでもどこでも利用できる。tuat.ac.jp/research/support/MATLAB.html　TUAT operates the MathWorks MATLAB Campus‑Wide License. All faculty and students can access MATLAB and nearly all MathWorks products, with no installation limits, anytime and anywhere.

Simulation hardware (workstation), 計算機

• HP Workstation, CPU : Intel ® Xeon® Processor X5690（3.46 GHz, 6 core) RAM: 32 GB; HD = 1 TB >> More

• Dell Precision 3660 Tower (water cooler high grade model) Win10Pro64bit, CPU: Intel Core i9-12900K (3.9-5.1 Hz, 16 Core), RAM: 64GB, 1 TB, M.2, PCIe NVMe, SSD, NVIDIA RTX A4000. > More




For sample preparation (before SEM, etc.) , 材料の前処理用

• JEOL Cross section polisher (using an ion beam): For samples too sensitive for mechanical polishing: Metals, ceramics, plastics, etc. jeol.co.jp/en/science/cp.html
• Osmium coater (Neoc-STB), （電子顕微鏡試料作製装置）
• クリオスタット（Cryostatl）for “soft” sample with few ten micrometer thickness.


For plant growth, 植物の実験用装置

• U-ING GreenFarmCube 水耕栽培器 Hydroponic unit. Integrated white LEDs (10,000 lux, 16 h/day), top exhaust fan with filter, and an air pump ensure light, airflow, and oxygenation for reliable growth of 23 vegetable varieties. User-friendly top control panel with timer and day counter, removable two-part lid for easy maintenance, and a buoyant seedling panel with a pickup hole to observe roots. 水耕栽培器。白色LED（10,000ルクス×16時間/日）、天面排気ファン（フィルター付）とエアポンプで光・換気・溶存酸素を確保し、23品種の野菜を安定栽培します。操作は天面の統合パネル（タイマー・日めくりカウンター）。浮遊式苗床パネルのピックアップホールで根の観察が可能。http://www.greenfarm.uing.u-tc.co.jp/
• Phytotron (2 x 2 x 2 m) (a completely closed greenhouse that can be used for study of environmental conditions on plant growth) in Fuchu campus. 6 units. (Managed by Izuta Lab.)

Heating-related system. 加熱装置

• Commercial-made heating system (microwave)
• Commercial-made heating system (electric furnace)
• Commercial-made Infra-Red Heating system, 遠赤外線ヒーター
• Lab-made heating system (tubular, electric furnaces)
• X-ray diffractometer (XRD) with heating system
• 熱分析: Thermo Gravimetry/Differential Thermal Analyzer (TG-DTA) Rigaku　https://rigaku.com/ja/products/thermal-analysis ひとつの試料で，示差熱分析（DTA：Differential Thermal Analysis）と熱重量測定（TG：Thermogravimetry）が同時に行える装置。温度プログラム(昇温速度制御)によって試料温度を変化させ、試料の化学・物理変化により生じる重量変化、温度変化を測定。試料の相転移温度(固相→固相、固体→液体、液体→気体)や、各種雰囲気における試料の反応性、熱安定性の評価ができる。さらに、速度論的解析から活性化エネルギーを算出することも可能。This instrument performs simultaneous Differential Thermal Analysis (DTA) and Thermogravimetry (TG) on a single sample. A controlled temperature program (heating-rate control) alters the sample temperature while recording weight changes and thermal signals that arise from chemical and physical transformations. The measurement atmosphere (gases) can be changed, enabling evaluation of phase-transition temperatures (solid–solid, solid→liquid, liquid→gas), reactivity under different atmospheres, and thermal stability. Kinetic analysis is also supported to compute activation energies.

Water-related instrument:

• Contact Angle Measurement System : To know the surface wetting characteristics 自動接触角計（協和界面化学株式会社） face-kyowa.co.jp/products/3-1_ContactAngle.html​
• Moisture Checker 佐藤計量器製作所（9.1～40.0 %）電気抵抗式 SK-960A TYPE1 www

For surface and structure measurement

• Non-contacting type Electrostatic voltmeters – Measuring surface potential (voltage) on materials. Trek model 323 表面電位計（100 VDC or peak AC, sensitivity 5mV）
• 2025: Kasuga Denki KSD-2000 (振動型表面電位センサー) from 0.1kv to 50kV (or from 0.01kV to 20kV) with analog output 0-500mV and working distance 50 mm or 100 mm (using an automatic distance meter)
• Micro-Raman spectrometer (Nicolet Almega) – This one needs heavy-revision
• Dektak surface profilometer (XT-S), 触針式表面形状測定器（段差計）
• Fluorescent microscope (OLYMPUS BX53) システム生物顕微鏡（正立顕微鏡）
• Built-in Biological Microscope Digital Camera 生物顕微鏡・デジタルカメラ内臓 DN-107T （USB2.0 (windows 7/8/10), 40-1000x, LED light, Resolution 1280 x 1024, 対物レンズ：4x, 10x, 40x, 100x）
• Laser microdissection +PALM MicroBeam (for isolating high-purity tissue) >> Movie

CAMERA

• CASIO. EXLIM. 6M pixel, High speed (max. 60 pictures/sec.;  Max. 1200 fps) 12 X optical zoom. Lens: 9群12枚, F2.7(W)～F4.6(T), f=7.3~87.6 mm) Macro: 5~50cm(W). Shutter: 60~1/40000 sec; USB/AVポート, HDMI™、output (mini), 外部マイク端子, 外部電源端子, Hi-Speed USB. >>> Samples@Youtube
• CASIO EXILIM EX-F1対応顕微鏡汎用アダプター　NY-F1 (85,050 yen) EX-F1対応リレーレンズ内蔵本体光学部,  先端径φ23.2mm, ミクロメーター 取り付け可能 口径変換リング：φ30ｍｍ顕微鏡接眼レンズ挿入部、及びCマウントに接続する場合にアダプター本体と併 用する口径変換用リング。 Cマウント取り付け用アダプター：　Cマウントに接続する場合に併用するアダプター。固定ネジ付き
• NIKON digital camera D5600 with Lens (AF-P DX NIKKOR 18-55mm f/3.5-5.6G VR DX), Remote code MC-DC2, AC-Adapter, and Power Connector EP-5A.

---

Electrical instruments

• DC power supply (Takasago KX-100H, Japan)
• Tektronix  TDS 2002B Benchtop Oscilloscopes; DIGITAL STORAGE, Bandwidth: 60 MHZ, Sampling rate: 1 GSa/s, 2-CH, COLOR DISPLAY, GPIB/USB PORTS, Input: 100 VAC to 240 VAC
• Amplifier (mono) max. 100 W (connected with a speaker)



Ultra-centrifugation:

• himac CR22N (Max: 22,000 rpm) with cooler 冷却遠心機（クラス最大処理容量6L ＋ 省スペース、新ローターR9A2（クラス初※の専用1.5Lボトル×4本）による6L大容量処理が可能）USB port 最大遠心加速度 58,700×g（R27Aローター）

Sun light simulator (JIS Japan Industrial Standard)

• 人工太陽照明灯SOLAX XC-500 EFSS (500 W) 350-2500nm, 1sun(1000W/m2). seric.co.jp/superspot/

Ultra Stirrer, Digital

ウルトラスターラー デジタル　MSD-1N 離れても使える強力スターラーでスタンドとの併用が可能。強力ネオジマグネット10個を磁力線が上に伸びるように配列をする事で、ウォーターバス等を置いても撹拌可能。強力マグネットと強力DCブラシレスモーターで高粘度試料の撹拌だけでなく、大型撹拌子（長さ100mm以上）にも対応。A powerful stirrer that can be used from a distance and can be used in conjunction with a stand. By arranging 10 powerful neodymium magnets so that the magnetic lines extend upwards, stirring is possible even when a water bath is placed on it. The powerful magnet and powerful DC brushless motor not only stir high-viscosity samples, but also support large stirrers (lengths of 100 mm or more).

For making surface “smoother”: 

For “size reduction”: Mixer/Blender/Milling

---

In other lab (same building) 共通設備 (SCOP, TUAT)

LC-MS（Thermo Scientific, Orbitrap Exploris™ 480 質量分析計（質量範囲:　40 ～ 8,000 m/z）Max. Resolution: Up to 480,000 at m/z 200

---
